Product Details:
|
| Quality Assurance: | AOI IQC PQC QA | Minimum Track/gap IL: | 0.075mm/0.075mm(3mil/3mil) |
|---|---|---|---|
| Min Annular Ring On Inner Layer One Side: | 3mil(0.075mm) | Maximum Cu Weight OL: | 6oz(210um) |
| Maximum Cu Weight 1L: | 12oz(420um) | Finished Board Thickness: | 0.20-6mm |
| Layer Count: | 2-52L | Layer To Layer Registration: | ±3mil(±76um) |
| Highlight: | 0.075mm Medical Electronics Assembly,3mil Medical Electronics Assembly,Multifunctional Medical Circuit Board |
||
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Quality Assurance | AOI IQC PQC QA |
| Minimum track/gap IL | 0.075mm/0.075mm(3mil/3mil) |
| Min annular ring on inner layer one side | 3mil(0.075mm) |
| Maximum Cu weight OL | 6oz(210um) |
| Maximum Cu weight 1L | 12oz(420um) |
| Finished board thickness | 0.20-6mm |
| Layer count | 2-52L |
| Layer to layer registration | ±3mil(±76um) |
| Hole position Accuracy | ±2mil(±50um) |
| Slot hloe Tolerance | ±3mil(±75um) |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
