Product Details:
|
| Special Process: | Partial Hybrid, Partial High Density | Max Aspect Ratio PTH: | 10:1 |
|---|---|---|---|
| NPTH Diameter Tolerance: | ±1mil(25±um) | Copper On The Wall Of The Holes: | 0.4-2mil |
| Grapic Pattern Registration Tolerance: | ±3mil | Package: | Vacuum, Anti-static, ESD |
| Layer Count: | 1-64 | PTH Diameter Tolerance: | ±2mil(±50um) |
| Highlight: | 64 Layers IOT Circuit Board,ISO9001 IOT Circuit Board,94v0 PCB Assembly Electronic |
||
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Special Process | Partial hybrid, Partial high density |
| Max Aspect ratio PTH | 10:1 |
| NPTH diameter tolerance | ±1mil(25±um) |
| Copper on the wall of the holes | 0.4-2mil |
| Grapic pattern registration tolerance | ±3mil |
| Package | Vacuum, Anti-static, ESD |
| Layer count | 1-64 |
| PTH diameter tolerance | ±2mil(±50um) |
| The track Etching tolerance | ±1mil(±25um) |
| Layer | 1-64 Layers |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
