Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: RoHS, ISO14001,
Model Number: HKCC2211YH96
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: USD8-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: L/C, T/T
Supply Ability: 6500PCS/WEEK
Input Power: |
5W |
Transmitting Distance: |
5-8mm |
Charging Current: |
1000mA |
Output: |
5V-1A |
Working Frequency: |
110-205KHZ |
Conversion Efficiency: |
76% |
Protective Measures: |
OCP, OTP, SCP |
SMT Mounter: |
12 Sets |
Input Power: |
5W |
Transmitting Distance: |
5-8mm |
Charging Current: |
1000mA |
Output: |
5V-1A |
Working Frequency: |
110-205KHZ |
Conversion Efficiency: |
76% |
Protective Measures: |
OCP, OTP, SCP |
SMT Mounter: |
12 Sets |
Wireless Charger Assembled Printed Circuit Boards Multipurpose 1-52 Layers
Product Description
Wireless Charger Transmit PCB Assembly With Power Bank PCBA Module OEM
Files and Requirment for PCB,PCBA quotation:
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
Specification:
Input power | 5W |
Transmitting distance | 5-8mm |
Charging current | 1000mA |
Output | 5V-1A |
Working Frequency | 110-205KHZ |
Conversion efficiency | 76% |
Protective measures | OCP,OTP,SCP |
SMT mounter | 12 sets |
Inspectation Equipments | AOI /Solder Paste Testing/Function Testing |
Layers |
1 to 52 layers
|
PCB board manufacture and PCBA service:
o PCB board made, circuit board parts purchased by us
o Electronic testing circuit board or PCBA
o Fast delivery, anti-static package
o RoHS Directive-compliant, lead-free
o One stop service from PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
o Eleectronic manufacturing service
Detailed terms for PCB assembly:
o Technical requirement:
§ Professional surface-mounting and through-hole soldering technology
§ Various sizes like 1206, 0805, 0603 components SMT technology
§ ICT (In Circuit Test), FCT (Functional Circuit Test) technology
§ PCB assembly with UL, CE, FCC, RoHS approval
§ Nitrogen gas reflow soldering technology for SMT
§ High standard SMT and solder assembly line
§ High density interconnected board placement technology capacity
o Quote requirement:
§ Gerber file and Bom list
§ Clear pics of pcba or pcba sample for us
§ Test method for PCBA
o PCB specification:
§ Layer: 1 to 12 layers
§ Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
§ Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25″)
§ Max. finished board side: 500 x 500mm (20 x 20”)
§ Min. drilled hole size: 0.25mm (10mil)
§ Min. line width: 0.10mm (4mil)
§ Min. line spacing: 0.10mm (4mil)
§ Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
§ Copper thickness: 0.5 to 3.0 oz
§ Solder mask color: green/black/white/red/blue
§ Inner packing: plastic bag
§ Outer packing: standard carton packing
§ Hole tolerance: PTH: ±0.076, NTPH: ±0.05
§ Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
§ Profiling punching: routing, V-cut, beveling
§ Providing OEM service to all sorts of printed circuit board assembly
