Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: SGS, RoHS, ISO14001
Model Number: HKCC2211YH155
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: USD10-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: T/T
Supply Ability: 5000PCS/WEEK
Gold Plating, Ni Thickness: |
1-6 U Inch |
Gold Plating, Au Thickness: |
1-6 U Inch |
ENIG Ni/Au Thickness: |
Ni:30-150u Inch Au:±1u Inch |
OSP: |
0.2-0.8um |
Die Punching Min Hole/tolerance: |
Min:0.5mm/±0.05mm |
Alignment Tolerance Of Manual Joint Operation: |
±0.15mm |
Voltage Of E-test: |
250±25V |
Short Circuit Impedance: |
≥100Ω |
Gold Plating, Ni Thickness: |
1-6 U Inch |
Gold Plating, Au Thickness: |
1-6 U Inch |
ENIG Ni/Au Thickness: |
Ni:30-150u Inch Au:±1u Inch |
OSP: |
0.2-0.8um |
Die Punching Min Hole/tolerance: |
Min:0.5mm/±0.05mm |
Alignment Tolerance Of Manual Joint Operation: |
±0.15mm |
Voltage Of E-test: |
250±25V |
Short Circuit Impedance: |
≥100Ω |
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Gold plating, Ni thickness | 1-6 u inch |
| Gold plating, Au thickness | 1-6 u inch |
| ENIG Ni/Au thickness | Ni: 30-150u inch Au:±1u inch |
| OSP | 0.2-0.8um |
| Die Punching Min hole/tolerance | Min:0.5mm/±0.05mm |
| Alignment tolerance of manual joint operation | ±0.15mm |
| Voltage of E-test | 250±25V |
| Short circuit impedance | ≥100Ω |
| Open-circuit impedance | ≥100Ω |
| Solderability testing | 245±5℃, 5Sec |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery, anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design, PCB layout, PCB manufacture, components purchasing
PCB assembly, test, packing and PCB delivery
Electronic manufacturing service
FAQ:
Q1: What service do you have?
A: We can offer one-stop service from PCB manufacturing to PCB assembling, testing,housing and other value-added service.
Q2. What specifications do you need for PCB quotation?
A: We need your PCB Gerber file,board thickness,copper thickness,surface finishing and quantity to quote you.
Q3. How do you ship the goods and how long does it take arrival?
A: We usually ship by DHL,UPS,FedEx and TNT.It takes 3-5 days to arrive.
