Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: ISO/RoHS/TS16949
Model Number: HKCC2211YH164
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: USD10-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: T/T
Supply Ability: 5000PCS/WEEK
Outline Tolerance: |
±0.05mm L≤25mm |
Trace Width Tolerance: |
±0.03mm W±30% |
Min. Gap Between Trace And Outline: |
0.2mm |
Min. Gap Between Cover Layer And Pad: |
0.1mm |
Min. PTH Hole Ring: |
0.45mm |
Min.Hole Size: |
0.15mm PTH |
Min.Line Width: |
0.05mm |
Mini Thickness: |
0.08mm |
Outline Tolerance: |
±0.05mm L≤25mm |
Trace Width Tolerance: |
±0.03mm W±30% |
Min. Gap Between Trace And Outline: |
0.2mm |
Min. Gap Between Cover Layer And Pad: |
0.1mm |
Min. PTH Hole Ring: |
0.45mm |
Min.Hole Size: |
0.15mm PTH |
Min.Line Width: |
0.05mm |
Mini Thickness: |
0.08mm |
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Outline Tolerance | ±0.05mm L≤25mm |
| Trace Width Tolerance | ±0.03mm W±30% |
| Min. Gap between Trace and Outline | 0.2mm |
| Min. Gap between Cover Layer and Pad | 0.1mm |
| Min. PTH Hole Ring | 0.45mm |
| Min.Hole Size | 0.15mm PTH |
| Min.Line Width | 0.05mm |
| Mini thickness | 0.08mm |
| Hole Size Tolerance | ±0.05mm |
| BGA ball pitch | 1.00mm (minimum), 3.00mm (maximum) |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
FAQ:
Q1: What service do you have?
A: We can offer one-stop service from PCB manufacturing to PCB assembling, testing,housing and other value-added service.
Q2. What specifications do you need for PCB quotation?
A: We need your PCB Gerber file,board thickness,copper thickness,surface finishing and quantity to quote you.
Q3. How do you ship the goods and how long does it take arrival?
A: We usually ship by DHL,UPS,FedEx and TNT.It takes 3-5 days to arrive.
