Home > products > PCBA Circuit Board > Smart Watch Nickle PCBA Circuit Board Immersion Silver For GPS Tracker

Smart Watch Nickle PCBA Circuit Board Immersion Silver For GPS Tracker

Product Details

Place of Origin: China

Brand Name: OEM Customized

Certification: ISO9001/ISO14001/CE

Model Number: HKCC2211YH12

Payment & Shipping Terms

Minimum Order Quantity: 5pcs

Price: USD10-USD100

Packaging Details: PCB: Vacuum Packing with Carton Box PCBA: Bubble bags with Carton Box

Delivery Time: 20 workdays

Payment Terms: L/C, T/T

Supply Ability: 5000PCS/WEEK

Get Best Price
Highlight:

Smart Watch PCBA Circuit Board

,

Nickle PCBA Circuit Board

,

GPS PCB PCBA assembly

Number Of Layer:
1,2,4,6,Up To 22 Layers
PCB Type:
Hard, Flexible, Rigid-Flexible
Solder Mask:
Green, Red, White, Yellow, Blue, Black, Etc
Silk Screen:
White, Yellow, Black, Or Negative, Etc
Surface Finish:
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP Etc
PCB Cutting:
Shear, V-score, Tab-routed
SMT Jointing Min. Space:
0201
Placement Capability:
0805, 0603, 0402, 0201
Number Of Layer:
1,2,4,6,Up To 22 Layers
PCB Type:
Hard, Flexible, Rigid-Flexible
Solder Mask:
Green, Red, White, Yellow, Blue, Black, Etc
Silk Screen:
White, Yellow, Black, Or Negative, Etc
Surface Finish:
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP Etc
PCB Cutting:
Shear, V-score, Tab-routed
SMT Jointing Min. Space:
0201
Placement Capability:
0805, 0603, 0402, 0201
Smart Watch Nickle PCBA Circuit Board Immersion Silver For GPS Tracker
Product Description

Smart Watch GPS Tracker Printed Circuit Board Electronic Control Board Lora Sensor





Files and Requirment for PCB,PCBA quotation:

  • A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
  • PCB Gerber files.
  • A PCB fabrication drawing and PCBA assembly drawing.
  • Test procedures.
  • Any mechanical restrictions such as assembly height requirements
  • PCB board manufacture and PCBA service:
    • o PCB board made, circuit board parts purchased by us
    • o Electronic testing circuit board or PCBA
    • o Fast delivery, anti-static package
    • o RoHS Directive-compliant, lead-free
    • o One stop service from PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
    • o Eleectronic manufacturing service
  • Detailed terms for PCB assembly:
    • o Technical requirement:
      • § Professional surface-mounting and through-hole soldering technology
      • § Various sizes like 1206, 0805, 0603 components SMT technology
      • § ICT (In Circuit Test), FCT (Functional Circuit Test) technology
      • § PCB assembly with UL, CE, FCC, RoHS approval
      • § Nitrogen gas reflow soldering technology for SMT
      • § High standard SMT and solder assembly line
      • § High density interconnected board placement technology capacity
    • o Quote requirement:
      • § Gerber file and Bom list
      • § Clear pics of pcba or pcba sample for us
      • § Test method for PCBA
    • o PCB specification:
      • § Layer: 1 to 12 layers
      • § Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
      • § Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25)
      • § Max. finished board side: 500 x 500mm (20 x 20”)
      • § Min. drilled hole size: 0.25mm (10mil)
      • § Min. line width: 0.10mm (4mil)
      • § Min. line spacing: 0.10mm (4mil)
      • § Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
      • § Copper thickness: 0.5 to 3.0 oz
      • § Solder mask color: green/black/white/red/blue
      • § Inner packing: plastic bag
      • § Outer packing: standard carton packing
      • § Hole tolerance: PTH: ±0.076, NTPH: ±0.05
      • § Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
      • § Profiling punching: routing, V-cut, beveling
      • § Providing OEM service to all sorts of printed circuit board assembly
Outer packing standard carton packing
Hole tolerance PTH: ±0.076, NTPH: ±0.05
Profiling punching routing, V-cut, beveling
Layer 1 to 12 layers
finished thickness 0.2 to 4.0mm (0.02 ~ 0.25″)
finished board side 500 x 500mm (20 x 20")
Min. drilled hole size 0.25mm (10mil)
Min. line width 0.10mm (4mil)
Min. line spacing 0.10mm (4mil)
Surface finish/treatment HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
