Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: CE/ROHS/ISO9001/Iso14001
Model Number: HKCC2211YH150
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: USD10-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: T/T
Supply Ability: 5000PCS/WEEK
Material: |
FR-4 94V0/ Aluminum |
Minimum Size: |
3mm*3mm |
Maximum Panel Size: |
50cm*45cm |
Surface Treatment: |
Immersion Silver: 0.1-1.2um |
Minimum Panel Size: |
7.5*7.5cm |
Tolerance Size Of Board(Outline): |
±0.2mm |
Board Thickness: |
0.4-2.4mm |
Tolerance Thickness Of Board( T≥1.0mm): |
±10% |
Material: |
FR-4 94V0/ Aluminum |
Minimum Size: |
3mm*3mm |
Maximum Panel Size: |
50cm*45cm |
Surface Treatment: |
Immersion Silver: 0.1-1.2um |
Minimum Panel Size: |
7.5*7.5cm |
Tolerance Size Of Board(Outline): |
±0.2mm |
Board Thickness: |
0.4-2.4mm |
Tolerance Thickness Of Board( T≥1.0mm): |
±10% |
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Material | FR-4 94V0/ Aluminum |
| Minimum Size | 3mm*3mm |
| Maximum Panel Size | 50cm*45cm |
| Surface treatment | Immersion silver: 0.1-1.2um |
| Minimum Panel Size | 7.5*7.5cm |
| Tolerance Size of Board(Outline) | ±0.2mm |
| Board Thickness | 0.4-2.4mm |
| Tolerance Thickness of Board( t≥1.0mm) | ±10% |
| Hole tolerance | PTH: +/-3mil NPTH: +/-2mi |
| Surface Finishing | Immersion Gold for flexible circuit board |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
