Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: SGS, RoHS, ISO14001
Model Number: HKCC2211YH151
Payment & Shipping Terms
Minimum Order Quantity: 2pcs
Price: USD10-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: T/T
Supply Ability: 5000PCS/WEEK
Min. Line Width: |
4mil(0.1mm) |
Min. Line Space: |
4mil(0.1mm) |
Outer Layer Copper Thickness: |
1OZ/2OZ/3OZ |
Surface Treatment: |
Gold Plating: Au 1-150U’’ |
Inner Layer Copper Thickness: |
35um/50um(1OZ/1.5OZ) |
Drill Diameter Range: |
0.2-6.3mm |
Annular Ring: |
≥0.1mm(4mil) |
Finished Hole Size: |
0.2--6.20mm |
Min. Line Width: |
4mil(0.1mm) |
Min. Line Space: |
4mil(0.1mm) |
Outer Layer Copper Thickness: |
1OZ/2OZ/3OZ |
Surface Treatment: |
Gold Plating: Au 1-150U’’ |
Inner Layer Copper Thickness: |
35um/50um(1OZ/1.5OZ) |
Drill Diameter Range: |
0.2-6.3mm |
Annular Ring: |
≥0.1mm(4mil) |
Finished Hole Size: |
0.2--6.20mm |
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Min. Line Width | 4mil(0.1mm) |
| Min. Line Space | 4mil(0.1mm) |
| Outer Layer Copper Thickness | 1OZ/2OZ/3OZ |
| Surface treatment | Gold plating: Au 1-150U’’ |
| Inner Layer Copper Thickness | 35um/50um(1OZ/1.5OZ) |
| Drill Diameter Range | 0.2-6.3mm |
| Annular Ring | ≥0.1mm(4mil) |
| Finished Hole Size | 0.2--6.20mm |
| The Size Tolerance of Finished Hole | ±0.08mm |
| Solder Mask Type | LPI |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
