Product Details:
|
| Base Material: | Polyimide | Material Thickness(mm): | 0.1-0.5mm |
|---|---|---|---|
| Board Outline Tolerance: | ±0.25mm | Mini Hole Size(mechanical): | 0.15mmPTH |
| Mini PTH Hole Ring: | 0.45mm | Trace Width Tolerance: | ±0.03mm,W±30% |
| Hole Size Tolerance: | ±0.05mm | Contours: | Scored, Routed, Punched |
| Highlight: | Polyimide Flexible Rigid PCB,Multipurpose Flexible Rigid PCB,Punched Flexible Circuit Assembly |
||
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements
PRODUCT PARAMETERS
| Base Material | Polyimide |
| Material Thickness(mm) | 0.1-0.5mm |
| Board Outline Tolerance | ±0.25mm |
| Mini Hole Size(mechanical) | 0.15mmPTH |
| Mini PTH Hole ring | 0.45mm |
| Trace width tolerance | ±0.03mm,W±30% |
| Hole size Tolerance | ±0.05mm |
| Contours | Scored, Routed, Punched |
| Min.Gap between Cover Layer and Pad | 0.1mm |
| Min.Gap between Trace and outline | 0.2mm |
PCB board manufacture and PCBA service:
PCB board made, circuit board parts purchased by us
Electronic testing circuit board or PCBA
Fast delivery,anti-static package
RoHC Directive-compliant, lead-free
One stop service from PCB design,PCB layout,PCB manufacture,components purchasing
PCB assembly,test,packing and PCB delivery
Electronic manufacturing service
