Product Details
Place of Origin: China
Brand Name: OEM Customized
Certification: ISO9001/SGS/CE/ROHS
Model Number: HKCC24YH252
Payment & Shipping Terms
Minimum Order Quantity: 5pcs
Price: USD1-USD100
Packaging Details: Inner packing :bubble bag Outer packing :Standard carton box
Delivery Time: 20 workdays
Payment Terms: T/T
Supply Ability: 10000PCS/WEEK
Countersink Tolerance: |
±0.15mm |
Inner Layer Min Trace/Space: |
3/3mil |
Contour Tolerance: |
±0.1mm |
Copper Thickness: |
0.4-2mil(10-50um) |
Min BGA: |
7mil |
Material: |
FR-4 And Polymide |
Min Laser Drilling: |
0.1mm |
PTH Tolerance: |
±0.075mm |
Countersink Tolerance: |
±0.15mm |
Inner Layer Min Trace/Space: |
3/3mil |
Contour Tolerance: |
±0.1mm |
Copper Thickness: |
0.4-2mil(10-50um) |
Min BGA: |
7mil |
Material: |
FR-4 And Polymide |
Min Laser Drilling: |
0.1mm |
PTH Tolerance: |
±0.075mm |
Files and requirment for PCBA quotation
A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements.
